Digital Microscope - Standard Working Distance / 20x-220x / Caps / 1.3MP | Dino Lite AM4515ZT

Digital Microscope with standard working distance, handheld design for portability, featuring continuous magnification from 20x -220x. Comes with interchangeable caps for protection from dust and liquids, alternative lighting and magnification, plus a precision calibration target. Ideal for non-destructive analysis, highly precise cleaning, characterisation tests and condition recording.

Additional caps allow further flexibility in use, i.e. sealed caps for dusty environments or protection from liquids
AMR (automatic magnification reading) shows clearly the level of magnification through the software
1.3 megapixel sensor providing 1280x1024 pixel resolution, capture video (30fps) and still images
20x-220x magnification
Polarizer filter allows you to reduce or eliminate glare on reflective surfaces and also can provide the ability to see through the surface of fully or partially transparent materials, such as textiles, paint, glass, and plastic
Complete with software (Windows and Mac compatible - read more here) and all necessary cables, simple USB 2.0 setup
Annotate and measure images to 0.001mm
8 (white) LED illumination which can be switched on or off
ABS plastic body with simple to operate dials for focus and polarisation

microscope specification

More details in 'Specification' tab below.

Available Accessories: Stands & stand accessories (see 'Recommended' items below), Image capture footswitch for hands-free operation (see below), WiFi streamer for wireless video streaming to mobile or desktop devices.

Code	Description	Pack Size	Price	Stock
P873-4515ZT 873-4515ZT	Microscope Dino-Lite Dino Lite AM4515ZT P873-4515ZT 873-4515ZT	Pack Size: Each	Price: £595.00 ex VAT	In-stock 14 days
Accessories to fit 873-4515ZT
P873-RK-06A 873-RK-06A	Microscope Stand RK-06A Dino Lite P873-RK-06A 873-RK-06A	Pack Size: Each	Price: £200.00 ex VAT	Low Stock
P873-RK-10A 873-RK-10A	Microscope Stand RK-10A Dino Lite P873-RK-10A 873-RK-10A	Pack Size: Each	Price: £270.00 ex VAT	In-stock 14 days
P873-MS52BA2 873-MS52BA2	Microscope Stand MS52BA2 P873-MS52BA2 873-MS52BA2	Pack Size: Each	Price: £320.00 ex VAT	In Stock 48hr
P873-RK-02 873-RK-02	Microscope Stand RK-02 P873-RK-02 873-RK-02	Pack Size: Each	Price: £130.00 ex VAT	Low Stock
P873-WF-10 873-WF-10	Microscope Wifi Streamer Dino Lite P873-WF-10 873-WF-10	Pack Size: Each	Price: £260.00 ex VAT	In Stock 48hr
P873-SW-F1 873-SW-F1	Microscope Foot Switch Dino Lite P873-SW-F1 873-SW-F1	Pack Size: Each	Price: £50.00 ex VAT	In Stock 48hr

Recommended
Specification
Alternatives

Microscope Stand - Professional Mid Range | Dino Lite

£200.00 ex VAT

Microscope stand RK-10 with extension arm

Microscope Stand - High Precision | Dino Lite

£270.00 ex VAT

Microscope Stand Accessories | Dino Lite

From £20.00 ex VAT

Microscope Stand - Flexi-arm with bench bracket | Dino Lite

£130.00 ex VAT

WiFi Streamer for Digital Microscopes - Cast to PC/Tablet/Mobile | Dino Lite

£260.00 ex VAT

Digital Microscope Footswitch | Dino Lite

£50.00 ex VAT

MAGNIFICATION RATE	WORKING DISTANCE 1	WORKING DISTANCE 2*	FIELD OF VIEW(X)	FIELD OF VIEW(Y)	DEPTH OF FIELD
Listed values may differ slightly		* Without front cap			Unit = mm
20	52.7	60.2	19.5	15.6	2.5
30	26.0	33.5	13.0	10.4	1.8
40	13.4	20.9	9.8	7.8	1.5
50	6.4	13.9	7.8	6.3	-
60	2.2	9.7	6.5	5.2	-
70	-	7.1	5.6	4.5	1.0
80	-	5.5	4.9	3.9	-
90	-	4.5	4.3	3.5	-
100	-	4.1	3.9	3.1	-
110	-	4.0	3.6	2.8	-
120	-	4.1	3.3	2.6	-
130	-	4.5	3.0	2.4	-
140	-	5.0	2.8	2.2	-
150	-	5.6	2.6	2.1	-
160	-	6.3	2.4	2.0	-
170	-	7.1	2.3	1.8	-
180	0.5	8.0	2.2	1.7	-
190	1.4	8.9	2.1	1.6	-
200	2.4	9.9	2.0	1.6	-
210	3.4	10.9	1.9	1.5	-
220	4.4	11.9	1.8	1.4	0.1

LIGHTING

Light/ LED type: White
Number of LEDs: 8
LED on/off switchable: Yes
Infrared filter: IR cut-filter >650 nm
Diffuser available: Yes (N3C-D included)
Emission filter: No
Polarizer: Yes, linear

OPTICS

Magnification: 20-220x
Macro zoom: No
Working distance: Standard
Lens type: Glass with anti-reflection coating

SENSOR

Sensor type: CMOS
Resolution: 1.3 Megapixel (1280x1024)
Maximum frame rate: 30 fps

COMPATIBILITY

Interface: USB 2.0
Operating system: Windows XP, Vista, 7, 8 & 10, MacOS 10.9 and up
Included software: DinoCapture 2.0 (Windows), DinoXcope (Mac OS)
Supported image formats (Windows): BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
Supported video formats (Windows): WMV, FLV, SWF
Supported image formats (MacOS): -
Supported video formats (MacOS): -
Imaging standards: DirectShow, UVC

HOUSING

Housing material: Composite/ plastic housing
Magnification lock: Yes
Dimensions: 10.5cm (L) x 3.2cm (D)
Weight: 105g
Cable length: 1.8m

FEATURES

Special feature: Aut. Magn. reading
Measurement: Yes
Calibration: Yes
Microtouch sensor: Yes
ESD safe: No

INFORMATION

Package contents:
Microscope, Carry pouch, Software CD, Calibration target, User manual, N3C-O- Open cap, N3C-C- Closed cap, N3C-D- Diffuser cap, N3C-Extension cap, N3C-L- Long cap, N3C-S- Side light cap
